Intel PK8071305501700 Xeon W5-3525 16 Core 32 Threads 3.2GHz Processor Only
INTEL | More PROCESSORS from INTEL · Part: PK8071305501700
Capacity Capacity: 3.2GHz
Availability 5-7 days
Product overview
The INTEL Xeon W5-3525 Processor Is A High-performance Workstation Processor Designed For Demanding Workloads. It Features 16 Cores And 32 Threads, Running At A Base Frequency Of 3.2 Ghz And Boosting Up To 4.8 Ghz. The Processor Is Equipped With 45 Mb Of INTEL Smart Cache And Supports Ddr5-4800 Memory. It Also Offers A Variety Of Advanced Technologies, Including INTEL Deep Learning Boost, INTEL Speed Shift Technology, And INTEL Virtualization Technology.
General Specifications
Code NameSapphire Rapids
Vertical SegmentWorkstation
Processor NumberW5-3525
LithographyINTEL 7
Embedded Options AvailableNo
Use ConditionsWorkstation
Cpu Specifications
Total Cores16
Performance-cores16
Efficient-cores0
Total Threads32
Max Turbo Frequency4.8 Ghz
INTEL Turbo Boost Max Technology 3.0 Frequency‡ 4.8 Ghz
INTEL Turbo Boost Technology 2.0 Frequency‡ 4.6 Ghz
Processor Base Frequency3.2 Ghz
Cache45 Mb INTEL Smart Cache
INTEL Upi Speed0 Gt/s
Max Of Upi Links0
Processor Base Power290 W
Maximum Turbo Power348 W
Memory Specifications
Max Memory Size (dependent On Memory Type)4 Tb
Memory TypesDdr5-4800(mt/s)
Maximum Memory Speed4800 Mhz
Max Of Memory Channels8
INTEL Optane Persistent Memory SupportedNo
Ecc Memory SupportedYes
Expansion Options
Direct Media Interface (dmi) Revision4.0
Scalability1s Only
Pci Express Revision5.0
Max Of Pci Express Lanes112
Package Specifications
Sockets SupportedFclga4677
Package CarrierE1a
Max Cpu Configuration1
Dts Max102 °c
Tcase75 °c
Package Size77.5mm X 56.5mm
Advanced Technologies
INTEL Quickassist Technology (qat)0 Default Devices
INTEL Dynamic Load Balancer (dlb)0 Default Devices
INTEL Data Streaming Accelerator (dsa)1 Default Devices
INTEL In-memory Analytics Accelerator (iaa)0 Default Devices
INTEL Advanced Matrix Extensions (amx)Yes
INTEL Deep Learning Boost (INTEL Dl Boost) On CpuYes
INTEL Speed Shift TechnologyYes
INTEL Turbo Boost Max Technology 3.0Yes
INTEL Turbo Boost Technology2.0
INTEL Hyper-threading TechnologyYes
INTEL Transactional Synchronization ExtensionsYes
INTEL 64Yes
Instruction Set64-bit
Instruction Set ExtensionsINTEL Sse4.1, INTEL Amx, INTEL Sse4.2, INTEL Avx2, INTEL Avx-512
Enhanced INTEL Speedstep TechnologyYes
Security & Reliability
INTEL Vpro EligibilityINTEL Vpro Enterprise
INTEL Software Guard Extensions (INTEL Sgx)No
INTEL Threat Detection Technology (tdt)No
INTEL Active Management Technology (amt)Yes
INTEL Remote Platform Erase (rpe)No
INTEL One-click RecoveryNo
INTEL Quickassist Software AccelerationNo
INTEL Platform Firmware Resilience SupportYes
INTEL Control-flow Enforcement TechnologyYes
INTEL Total Memory Encryption - Multi KeyNo
INTEL Total Memory EncryptionYes
INTEL Aes New InstructionsYes
INTEL Os GuardYes
INTEL Trusted Execution TechnologyYes
Execute Disable BitYes
INTEL Boot GuardYes
Mode-based Execute Control (mbec)Yes
Availability5-7 days
Manufacture WarrantyNone.
Our Warranty90 Days.
